AC  Alternating Current (vs DC)
ACK  Acknowledge (logic signal)
ACIA  Asynchronous Communication Interface Adapter
ACL  Advanced CMOS Logic (as in 74ACL245)
A/D  Analog to Digital
AF  Audio Frequency
AFC  Automatic Frequency Control
AGC  Automatic Gain Control AI Artificial Intelligence
ALC  Automatic Level Control
ALU  Arithmetic Logic Unit
A/N  Alphanumeric
ANSI  American National Standards Institute
ARRL  American Radio Relay League
AS  Advanced Schottky (as in 74AS245)
ASIC  Application-Specific Integrated Circuit
ASK  Amplitude-Shift Keying
ATC  Air Traffic Control
AV  Audio/Visual
AVC  Automatic Volume Control

BASIC  Beginners' All-purpose Symbolic Instruction Code
BBD  Bucket Brigade Device
BCD  Binary Coded Decimal
BEV  Billion Electron Volts
BIFET  BIpolar Field-Effect Transistor
BNC  Baby N Connector
BPI  Bits Per Inch
BPS  Bits Per Second
BTW  By The Way B&W Black & White (TV)
BW  BandWidth


CAD  Computer Assisted Design
CADA  Computer Assisted Design and Analysis
CADD  Computer Assisted Design and Development
CAE  Computer Assisted Engineering
CAM  Computer Assisted Manufacturing
CAN  CANcel
CAS  Column-Address Strobe (logic signal)
CATV  CAble TeleVision
CB  Citizens' Band
CBI  Complementary Binary
CC  Constant Current
CCD  Charge Coupled Device (used in cameras)
CCITT  International Telegraphy and Telephony Consultative Committee
CCTV  Closed Circuit TeleVision
CCW  Counter Clock-Wise
CD  Compact Disk
CD-I  Compact Disk - Interactive
CD-ROM  Compact Disk - Read Only Memory
CECL  Cascode Emitter-Coubled Logic
CEMF  Counter ElectroMotive Force
CerDIP  Ceramic Dual Inline Package
CES  Consumer Electronics Show
CF  Center Frequency
CFM  Cubic Feet per Minute
CISC  Complex Instruction Set Computer (vs RISC)
CL  Current Loop
CMOS  Complementary Metal Oxide Semiconductor
CP/M  Control Program for Microcomputers (operating system)
CPI  Character Per Inch
CPU  Central Processing Unit
CRC  Cyclic Redundancy Check (error detection scheme)
CRT  Cathode Ray Tube (TV/Monitor display, vs LCD)
CS  Control Strobe (logic signal)
CSA  Canadian Standards Association (UL's Canadian counterpart)
CTC  Counter/Timer Circuit
CTS  Clear To Send (protocol signal)
CV  Constant Voltage
CVT  Constant Voltage Transformer
CW  ClockWise


D/A  Digital to Analog
DAC  Digital to Analog Converter | Data Acquisition and Control
DARPA  Defense Advanced Research Projects Agency
DAV  Data AValiable | DatA Valid (logic signal)
dB  deciBel
DBA  DeciBels - Adjusted
DBK  DeciBels - referred to 1 Kilowatt
dBM  DeciBels - above or below 1 milliwatt
DBV  DeciBels - Voltage
DBX  DeciBels - above reference coupling
DC  Direct Current (vs AC)
DCD  Data Carrier Detect (protocol signal)
DES  Data Encription Standard
DIAC  Bilateral trigger diode
DIL  Dual In Line
DIN  Deutsche Industrie Normenausschuss
DIP  Dual Inline Package
DLC  Dual-Layer Capacitor
DMA  Direct Memory Access
DMM  Digital MultiMeter
DOD  Department of Defense
DOS  Disk Operating System
DOT  Department of Transportation
DP  Data Processing
DPDT  Dual Pole Dual Throw (as in a switch)
DPI  Dots Per Inch (as in resolution)
DPST  Dual Pole Single Throw (as in a switch)
DRAM  Dynamic Random Access Memory
DS  Data Strobe (logic signal)
DSO  Digital Storage Oscilloscope
DSP  Digital Signal Processing
DTL  Diode Transistor Logic (predecessor of TTL)
DTMF  Dual Tone Multi-Frequency (aka Touch Tones(tm))
DTR  Data Terminal Ready (protcol signal)
DVM  Digital Volt-Meter


E2PROM  Electricaly Erasable Programmable Read Only Memory
EAPROM  Electricaly Alterable Read Only Memory
EBCDIC  Extended Binary Coded Decimal Interchange Code
ECC  Error Checking and Correction
ECL  Emitter Coupled Logic
EEPROM  Electricaly Erasable Programmable Read Only Memory
EGA  Enhanced Graphics Adapter
EIA  Electronics Industries Association
EL  ElectroLuminescent
ELF  Extremly Low Frequency
EMF  ElectroMotive Force
EMI  ElectroMagnetic Interference
EMP  ElectroMagnetic Pulse
ENIAC  Electronic Numerical Integrater and Computer (aka first computer)
EOT  End Of Transmission (protocol signal)
EPLD  Electricaly Programmable Logic Device
EPROM  Electricaly Programmable Read Only Memory (UltraViolet erased)
EQ  EQualizer
ESA  European Space Agency
ESD  Electrostatic Sensitive Device (aka CMOS :-)
ESR  Equivalent Series Resistance
EV  Electron Volt


F  Farad (measure of capacitance)
FAA  Federal Aviation Administration
FAST  Fairchild Advanced Schottky TTL (as in 74F245)
FAX  Facsimile FCC Federal Communications Commision
FDC  Floppy Disk Controller
FET  Field Effect Transistor
FF  Flip Flop
FFT  Fast Fourier Transform
FIFO  First In First Out
FILO  First In Last Out
FM  Frequency Modulation
FORTRAN  FORmula TRANslation
FP  Floating Point
FPLA  Field Programmable Logic Array
FPU  Floating Point Unit
FSK  Frequency-Shift Keying
FTP  File Transfer Protocol
FUBAR  Fouled/F***ed Up Beyond Any Recognition/Repair
FVC  Frequency to Voltage Converter


GA  Gate Array
GAL  Generic Array Logic
GCS  Gate Controller Switch
GFCI  Ground Fault Circuit Interrupter
GFI  Ground Fault Interrupter
GFLOPS  Billions of FLOating Point operations per Second
GIGO  Garbage In Garbage Out
GND  GrouND
GPIB  General Purpose Interface Bus
GPS  Global Positioning System



HAL  Hardwired Array Logic
HC  High speed Cmos (as in 74HC245)
HCT  High speed Cmos with Ttl thersholds (as in 74HCT245)
HD  High Density
HDC  Hard Disk Controller
HDTV  High Definition TeleVision
HDX  Half DupleX
HER  High Efficiency Red (as in a LED)
HET  Hetetodyne
HF  High Frequency
HFS  Hierarchical File System
HIC  Hybrid Integrated Circuit
HP  Hewlett Packard (company) | Horse Power
HPIB  Hewlett Packard Interface Bus
HPIL  Hewlett Packard Interface Loop (as in HP41CX calculator)
HTL  High Threshold Logic
HVDC  High Volatage Direct Current
HVPS  High Volatage Power Supply
Hz  Hertz (cycles per second)

I2ICE  Integrated Instrumentation and InCircuit Emulation
IA  Instrumentation Amplifier
IC  Integrated Circuit
ICE  InCircuit Emulation
IEEE  Institute of Electrical and Electronics Engineers
IF  Intermediate Frequency
IGFET  Insulated Gate Field Effect Transistor
IMHO  In My Humble Opinion
IMNHO  In My Not so Humble Opinion
IOB  Input/Output processor
IP  Interface Processor
IR  Current/Resistance | InfraRed
IRED  InfraRed Emitting Diode
ISA  Instrument Society of America
ISN  Information Systems Network
ISO  In Search Of


JEDEC  Joint Electron Device Engineering Council
JFET  Junction Field Effect Transistor
JIS  Japanese Industrial Standard
JPL  Jet Propulsion Laboratory
JUG  Joint Users Group

K  Kilo (1000 units)
KA  KiloAmpere (1000A)
KBPS  KiloBits Per Second
KEV  Kilo Electron Volts
KHz  Kilo Hertz (1000 cycles per second)
KVA  Kilo Volt Amperes
KWH  Kilo Watt Hours


L  Inductance
L2FET  Logic Level Field Effect Transistor
LAN  Local Area Network
LASCR  Light Activated Silicon Controlled Rectifier
LASER  Light Amplification by Stimulated Emission of Radiation
LC  Inductance and Capacitance
LCD  Liquid Crystal Display
LCM  Least/Lowest Common Multiple
LD  Line Driver
LED  Light Emitting Diode
LF  Low Frequency
LIFO  Last In First Out
LISP  LISt Processing (language)
LO  Local Oscillator
LORAN  LOng RAnge Navigation
LP  Low Pass
LPC  Linear Predictive Coding
LPM  Lines Per Minute
LPT  Line PrinTer (port - aka parallel port - of IBM PC fame)
LSB  Least Significant Bit
LSD  Least Significant Digit
LSI  Large Scale Integration
LUT  Look Up Table
LW  Long Wave


MB  MegaBytes (1024 * 1024 bytes)
MBPS  Million Bytes Per Second
MCA  Micro Channel Architecture (IBM PS/2's bus)
MCU  MicroComputer Unit
MDAC  Multiplying Digital to Analog Converter
MECL  Motorola Emitter Coupled Logic
MFLOPS  Millions of FLOating Point operations per Second
MFM  Modified Frequency Modulation
MHz  MegaHertz
MIDI  Music Instrument Digital Interface
MIL  MILitary
MIPS  Millions of Instructions Per Second
MMU  Memory Management Unit
MO  Master Oscillator
MOS  Metal Oxide Semiconductor
MOSFET  Metal Oxide Semiconductor Field Effect Transistor
MOV  Metal Oxide Varistor
MPU  Main Processing Unit
MR  Magnetic Resonance
MS-DOS  MicroSoft Disk Operating System
MSB  Most Significant Bit
MSD  Most Significant Digit
MSI  Medium Scale Intergration
MTBF  Mean Time Between Failures
MTS  Multichannel Television Sound (aka Stereo TV)
MUX  Multiplexer


NASA  National Aeronautics and Space Administration
NC  Not Connected (pin) | Normally Closed (switch/relay)
NEDA  National Electronics Distributors Association
NEMA  National Electrical Manufacturers Association
NF  NanoFarad (measure of capacitance)
NFS  Network File Server
NiCad  Nickel Cadmium (rechargable battery) TM of Saft America
NMOS  N-channel Metal Oxide Semiconductor
NMR  Nuclear Magnetic Resonance
NO  Normally Open (switch/relay)
NOAA  National Oceanic and Atmospheric Administration
NORAD  NORth American Defense
NPN  Negative Positive Negative (as in 2N2222 transistor)
NPO  Negative Positive 0 temperature coefficient (cermaic capacitors)
NPR  Nations Public Radio
NRZ  Non Return to Zero
NRZI  Non Return to Zero Invert
NSB  National Science Board
NSF  National Science Foundation
NSPE  National Society of Professional Engineers
NT  Network Terminator
NTC  Negative Temperature Coefficient
NTSC  National Television Systems Committee (Never The Same Color twice :-)


OC  Open Collector
OCR  Optical Character Recognition
OEM  Original Equipment Manufacturer
OS  Operating System
OSCAR  Orbiting Satellite Carrying Amateur Radio
OSHA  Occupational Safety and Health Administration
OTDR  Optical Time Domain Reflectrometry
OTOH  On The Other Hand
OTP  One Time Programmable (as in PROM or plastic EPROM)
OVP  Over Voltage Protection


PA  Power Amplifier | Public Address
PAL  Programmable Array Logic (TM of Monolithic Memories)
PBX  Perivate Branch eXchange
PC  Personal Computer | Printed Circuit | Program Counter
PCB  Printed Circuit Board
PCC  Plastic Chip Carrier
PCM  Pulse Code Modulation
PEC  PhotoElectric Cell
PF  Power Factor
PG  Power Gain
PGA  Pin Grid Array
PIA  Peripheral Interface Adapter
PIC  Priority Interrupt Controller | Prallax'es microcontroller name
PIV  Peak Inverse Voltage
PLA  Programmable Logic Array
PLCC  Plastic Leaded Chip Carrier
PLD  Programmable Logic Device
PLL  Phase Locked Loop
PM  Phase Modulation | Pulse Modulation
PNP  Positive Negative Positive (transistor)
POS  Point Of Sale
POV  Peak Operating Voltage
PPM  Parts Per Million
PPS  Pulses Per Second
PRN  Pseudo Random Noise
PROM  Programmable Read Only Memory
PSG  Programmable Sound Generator
PSI  Pounds per Square Inch (pressure)
PSK  Phase Shift Keying
PTT  Push To Talk (microphone)
PUT  Programmable Unijunction Transistor
PV  PhotoVoltaic
PWM  Pulse Width Modulation


QA  Quality Assurance
QC  Quality Control
QIC  Quarter Inch Cartridge
QIP  Quad Inline Package
QSM  Quad Surface Mount



R&D  Research and Development
RAD  Radiation Absorbed Dose
RADAR  RAdio Detection And Ranging
RAM  Random Access Memory
RAS  Row Address Strobe (logic signal)
RC  Radio Control | Resistance and Capacitance
RCV  ReCeiVe
RD  Receive Data | ReaD (logic signal)
RDA  Deceive Data
REM  Roentgen equivalent man
REP  Roentgen equivalent Physical
RET  RETurn
RF  Radio Frequency
RFI  Radio Frequency Interference
RGB  Red Green Blue
RH  Relative Humidity
RHDP  Right Hand Decimal Point
RISC  Reduced Instruction Set Computer (vs CISC)
RLC  Resistance Inductance Capacitance
RLG  Ring Laser Gyroscope
RMI  Radio Magnetic Interference
RMS  Root Mean Square
ROM  Read Only Memory
RPM  Revolutions Per Minute
RPN  Reverse Polish Notation (as in HP calculators)
RPS  Revolutions Per Second
RS  Reed Solomon (error correction)
RT  Real Time | Rise Time
RTD  Resistance Temperature Detector
RTI  Real Time Interrupt
RTL  Resistor Transistor Logic
RTOS  Real Time Operating System
RTS  Request To Send (protocol signal)


S/H   Sample and Hold
S/N   Signal to Noise (ratio)
SAW   Surface Acoustic Wave
SBC   Single Board Computer
SCA   SubCarrier Adapter
SCI   Serial Communication Interface
SCL   Serial CLock
SCR   Silicon Controller Rectifier
SCS   Silicon Controller Switch
SCSI   Small Computer System Interface
SDI   Strategic Defense Initiative
SEM   Scanning Electron Microscope
SEMI   Semiconductor Equipment and Materials Institute
SFC   polyStyrene Film Capacitor
SG   Signal Ground
SI   Systeme International (international system of units)
SIMM   Single Inline Memory Module
SIO   Serial Input and Output
SIPO   Serial In Parallel Out
SLC   Sigle Layer Ceramic (capacitor)
SM   Surface Mount
SMD   Surface Mount Device
SNR   Signal to Noise Ratio
SO   Serial Output | Small Outline | Significant Other
SOIC   Small Outline Integrated Circuit
SOJ   Small Outline J-leaded (chip package)
SOLV   SOLenoid Valve
SONAR   SOund NAvigation and Ranging
SOP   Small Outline Package
SP   Signal Processor | Stack Pointer
SPDT   Single Pole Double Throw (switch)
SPI   Serial to Parallel Interface
SPICE   Simulation Program with Integrated Circuit Emphasis
SPL   Sound Pressure Level
SPST   Single Pole Single Throw (switch)
SQL   Structured Query Language (for databases)
SR   Shift Register
SRAM   Static Random Access Memory
SSB   Single SideBand
SSI   Small Scale Integration
SSR   Solid State Relay
SSTV   Slow Scan TeleVision
SW   Short Wave

T/H  Track and Hold
TC  Temperature Coefficient
TCP/IP  Transmission Control Protocol/Internet Protocol
TD  Tunnel Diode
TDD  Telecomunication Devices for the Deaf
TEM  Transverse Electromagnetic (wave)
TF  Transfer Function
TFD  Thin Film Detector
TFEL  Thin Film ElectroLuminescent
TFT  Thin Film Transistor
THD  Total Harmonic Distortion
THz  TetraHertz
TIG  Tungsten Inert Gas
TM  Transverse Magnetic (wave)
TR  Transient Response
TS  Time Sharing
TTL  Transistor Transistor Logic
TV  TeleVision
TWT  Traveling Wave Tube

UART   Universal Asynchronous Receiver/Transmitter uF micro Farad (measure of capacitance)
UHF   Ultra High Frequency
UHV   Ultra High Vacuum
UJT   UniJunction Transistor
UL   Underwriters Laboratories
ULSI   Ultra Large Scale Integration
UPC   Universal Product Code
UPS   Uninterruptible Power Supply
USART   Universal Synchronous/Asynchronous Receiver/Transmitter
UTC   Universal Time Code
UV   UltraViolet
UVA   UltraViolet Alpha
UVB   UltraViolet Beta

VA  Volt Ampere
VAC  Volts Alternating Current
VAR  VARiable
VCC  Supply Voltage - positive
VCD  Variable Capacitance Diode
VCO  Voltage Controlled Oscillator
VCR  Video Cassette Recorder
VDC  Volts Direct Current
VDD  Supply Voltage - negative
VF  Vacuum Fluorecent
VFC  Voltage to Frequency Converter
VFO  Variable Frequency Oscillator (vs a crystal oscillator)
VHF  Very High Frequency
VLF  Very Low Frequency
VLSI  Very Large Scale Integration
VLT  Video Look up Table
VOL  VOLume
VOM  Volt OhmMeter
VOX  Voice Operated transmit ("trans" = X as in "Xmitter")
VR  Voltage Regulator
VRAM  Video Random Access Memory (aka Very fast RAM)
VS  Vertical Sync
VSS  Supply Voltage - Negative
VT  Virtual Terminal
VTM  Voltage Tunable Magnetron
VTVM  Vacuum Tube Volt Meter
VXO  Variable crystal Oscilator

WACK  Wait before ACKowledge
WDT  Watch Dog Timer
WHR  Watt HouR
WP  Word Processor
WPM  Words Per Minute
WR  WRite (logic signal)
WV  Working Voltage
WW  Wire Wound | Wire Wrap

XMT  TransMiT

YAG   Yttrium Aluminum Garnet (laser)
YIG   Yttrium Iron Garnet

ZD   Zero Defects
ZIF   Zero Insertion Force
ZIP   Zigzag Inline Package | Compression scheme


Courtesy of : www.qsl.net/yo5ofh


Go Back Go Top Go Home
